balustrades

Channel Balustrades
& Pool Fences

A clean uninterrupted look to blend in with the structure or surroundings. Face fix, top mount or recessed options available

channel balustrade

Panoramic Precision + Robust Design

Our durable channel systems provide a sleek continuous design for pool fencing and balustrading. Top mounted, side-fixed or recessed fixing options are all available in a range of finishes. Any railing, clips and brackets are co-ordinated and can be powdercoated to match the channel. Channel systems are quite flexible in that they allow for wider panels of glass to be used than other styles.

Contact us today for a free measure and quote in the Greater Auckland region

features
features

Channel Systems

Quality Materials

Channel is manufactured from architectural heavy duty 6063 T6 grade aluminium with anodised covers for added durability. The ability to accommodate 12mm up to 21.52mm thick glass makes this system ideal for use in homes, apartments and commercial projects.

Various Finishes

Available in satin stainless and polished stainless as standard with a selection of custom powdercoated finishes possible by request. Alternatively, a discrete recessed option is possible where channel can be embedded into the structure for an 'invisible' hardware design.

Indoor/Outdoor Flow

The same look and style of channel can be used in a variety of settings. From balconies and staircases to pool fences, in both top-fixed and face-fixed options. Matching your internal balustrades with the pool fence outside isn't a problem.

details
Technical

details

Channel Styles

channel
Face Fixed - Lugano

A minimalistic aluminium channel system for face-fixing balustrades which allows for long panels of glass and keeps the clean lines and square edges consistent with modern home trends. The fixings are concealed beneath a slim profile aluminium cover plate which can be powder-coated any of the standard colours to blend with the building structure. A rotating pressure plate system allows for a 30mm tilt and lock adjustment, backwards and forwards. This reduces issues arising from uneven sites or deck movement and allows for easy adjustment.

channel
Top Mount - Anzio

An easy-to-install system with a sleek minimalistic design. Anzio channel is versatile and suitable for use in a wide variety of applications from pool fencing to balustrades, walkways and staircases. Unlike many other balustrading systems, it does not need scaffolding and can be installed from the inside of a deck or balcony. This advantage serves to keep this system cost-effective.

Grades of Safety

Grade 1 - Toughened

rail balustrade

If our channel system is used with a full length top rail or is not protecting a fall greater than 1m; toughened safety glass can be used. The glass is 12-15mm thick and clamped into the channel. In the unlikely event of a breakage, the glass shatters into small fragments. Although the small individual fragments may be sharp on some edges, it is far less dangerous than the shards produced if a sheet of traditional float glass breaks.

Grade 3 - Frameless Sentry Glass

sentry glass balustrade

For the frameless look when protecting a fall greater than 1 metre, Sentry Glass must be used. Highly resistance to collapse, Sentry Glass interlayers are five times stronger and up to 100 times more rigid than other conventional interlayers. The interlayer stays together and upright even when both panes of glass have been broken.

If the glass ever breaks, fragments remain firmly bonded to the sentry glass interlayer, eliminating glass falling to the ground or over the edge.The glass retains its clarity, is extremely durable and resistant to clouding.

Colours - Finishes

mannex black Mannex Black
mannex charcoal Mannex Charcoal
mannex grey friars Mannex Grey Friars
mannex ironsand Mannex Ironsand
mannex sandstone grey Mannex Sandstone Grey
mannex silver pearl Mannex Silver Pearl
matt titania Matt Titania
matt appliance white Matt Appliance White
